Refrigerated Container Electrical Requirements
- Electrical System Compatibility: Cascade Vaults' reefer units require a three-phase electrical system. The standard supply voltage is 440/460 volts. Units can also operate with 208/230 volt three-phase transformers and are compatible with both 50 and 60 Hz frequencies.
-
Grounding and Circuit Protection: A grounded power supply is mandatory for safety. For 440/460 volt systems, a minimum of 30-amp circuit breakers is required, while 208/230 volt systems should have circuit breakers rated at a minimum of 50 amps.
-
Voltage Tolerance: The reefer containers are designed to accommodate a voltage variance of (+) or (-) 15%, providing flexibility in varying power conditions.
-
Professional Installation: We recommend that a certified electrician perform the installation. The units come with an external disconnect feature and can handle large variances in voltage and frequency, including international standards (50Hz).
-
Delivery and Plug Specifications: Each reefer container is equipped with a 460-volt cable and an ISO standard CE power plug (18 meters/59 feet in length).
-
Surge Protection: Our reefer units are equipped with internal circuit breakers and fuses for protection against power surges. However, external surge protection measures are strongly advised.
-
Welding Guidelines: Avoid arc welding on or near the container or any conductive surface it is resting on. This is to protect the sensitive electronic circuits in the control system from damage.
-
Rotation Auto-Correction: The units feature an auto-correction system for rotation on startup, simplifying the setup process and ensuring operational efficiency.
Additional Guidelines for Optimal Performance:
- Ventilation: Ensure the container is placed in a well-ventilated area to facilitate efficient airflow and cooling system performance.
- Regular Maintenance: Schedule regular maintenance checks to ensure the longevity and optimal performance of the reefer unit.
- Safe Operating Practices: Adhere to all safety guidelines and operational procedures as outlined in the user manual to ensure safe and effective use of the container.
- Service Support: Are team is available for technical support in case of problems or breakdowns.
For more information or specific inquiries, please contact Cascade Vaults’ support team.
